Stable Roving Frames

Short Description:

Advantage Of Our Stable Roving Frames: Roving frame is a spinning machine that makes roving from fiber strips. Roving frame is divided into wing roving frame and rolling roving frame according to the form of ream mechanism. The roving frame produces roving yarn by continuously applying ream to the yarn by rotating the roving wing. The roving machine uses a pair of rubber sheets to clip the yarn and form a false ream on the yarn. Flyer roving frame and rubbing roving frame can be divided into ...


  • FOB Price: Variable
  • Min.Order Quantity: 100 Units
  • Supply Ability: 10000 Units per Month
  • Payment Terms: L/C,D/P,D/A,T/T
  • Main Port: Shanghai,Ningbo,ShenZhen,TianJin
  • Product Detail

    Product Tags

    Advantage Of Our Stable Roving Frames:

    Roving frame is a spinning machine that makes roving from fiber strips. Roving frame is divided into wing roving frame and rolling roving frame according to the form of ream mechanism. The roving frame produces roving yarn by continuously applying ream to the yarn by rotating the roving wing. The roving machine uses a pair of rubber sheets to clip the yarn and form a false ream on the yarn. Flyer roving frame and rubbing roving frame can be divided into head, two and one – way roving frame. The feeding form of roving frame, roving winding and the number of spindles are different, but the machine structure and function are basically the same.

    Specifications

    • Spindle pitch: 216 mm
    • Pitch: 432 (4 spindle per section)
    • Number of spindle: 96, 108, 120
    • Draft range: 4.2-12 times
    • Twist range: 18.5-80 twist/m
    • Suitable spinning density: 238-1176 tex
    • Spindle speed: 1200 rpm/min

    Features

    • High quality
    • Wide adaptability and low consumption
    • Easy to operate and maintain
